mSATA
Ultra iSLC Solution
mSATA mini 3IE7
Features
- Up to 100K P/E cycle, extending the lifespan by 33x
- Utilizes Ultra iSLC Technology
- Equipped with 112-layer 3D TLC NAND Flash
- Supports temperatures -40°C to 85°C
- 5 years warranty and longevity commitment
The Innodisk mSATA mini 3IE7 is a SATA III 6.0 Gb/s flash-based drive tailored for industrial applications. Powered by exclusive Ultra iSLC Technology, it delivers up to 100K P/E cycles, greatly enhancing the drive's lifespan. It also includes a Thermal Sensor and iData Guard, ensuring data integrity and reliability in industrial environments.
100K P/E CYCLE, 33X LIFESPAN
The mSATA mini 3IE7, featuring BiCS5 112-layer 3D TLC NAND Flash and Innodisk's exclusive Ultra iSLC Technology, achieves an industry-leading 100K P/E cycle. This advancement extends the device lifespan by 33 times compared to conventional 3D TLC NAND Flash.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
EMPOWERING TELECOM NETWORKS: OVERCOMING DATA OVERLOAD WITH iSLC TECHNOLOGY
In today's fast-evolving telecommunications landscape, the demand for intensive network transmissions has reached unprecedented levels. For leading telecommunications service providers, this rapid surge brings a series of intricate challenges that demand immediate attention.
SPECIFICATIONS
| Model Name | mSATA mini 3IE7 |
|---|---|
| Flash Type | iSLC (3D TLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | MO-300B |
| Capacity | 20GB ~ 320GB |
| Sequential R / W (MB/sec, max.) | 550 / 490 |
| P/E Cycle | 30,000 / 100,000 |
| TBW (Max.) | 20,000 |
| Storage Temperature | -40°C ~ 85°C |
| Max. Power Consumption | 1.7W |
| Max. Channels | 4 |
| External DRAM Buffer | N |
| Feature | AES, H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 29.85 x 26.8 x 3.85 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
20GB | DHMSM-20GDK1KCASL | DHMSM-20GDK1KWASL |
40GB | DHMSM-40GDK1KCADL | DHMSM-40GDK1KWADL |
80GB | DHMSM-80GDK1KCA&L | DHMSM-80GDK1KWA&L |
160GB | DHMSM-A60DK1KCAQL | DHMSM-A60DK1KWAQL |
| 320GB | DHMSM-D2GDK1KCAQL | DHMSM-D2GDK1KWAQL |
&. S : 1 channel / D : 2 channels / Q : 4 channels
