M.2
128GB ~ 2TB
M.2 (S80) 3TG6-P
Features
- High IOPS
- AES-256 encryption
- Excellent random performance
- End-to-end Data Path Protection
- iData Guard for abnormal power failure
- PLP (iCell) technology for data protection (optional)
- Compatible with M.2 2280-D2-B-M standard
- Supports wide temperature from -40°C to 85°C
Innodisk M.2 (S80) 3TG6-P is SATA III 6Gb/s solid state disk, which delivers excellent performance, especially in random data transfer rate, and which offers reliability making it the ideal solution for a variety of applications, including embedded system, industrial computing, and enterprise field.
M.2 (S80) 3TG6-P not only performs unmatched performance, but also designed with Innodisk owned technical knowhow to ensure the data integrity and highest levels of reliability. Equipped with Error Correction Code (ECC) technology, it provides comprehensive End-to-End Data Path Protection (ETEP), ensuring secure data transmission between the host system and NAND Flash.
Innodisk M.2 (S80) 3TG6-P is designed for industrial field, and supports several standard features, including TRIM, NCQ, and S.M.A.R.T. In addition, Innodisk’s exclusive industrial-oriented firmware provides a flexible customization service, making it perfect for a variety of industrial applications.
iCell Technology – POWER LOSS PROTECTION
Innodisk's iCell Technology safeguards mission-critical data on DRAM-based SSDs during unexpected power failures. Integrated iCells deliver an instantaneous charge to ensure data is securely stored, preventing any loss and ensuring data integrity.
AES 256-bit DATA ENCRYPTION & TCG Opal 2.0 SUPPORT
Innodisk SSDs utilize AES 256-bit encryption, the US government’s standard for securing confidential data, while also supporting TCG Opal 2.0 for enhanced device management and user-friendly authentication.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
SPECIFICATIONS
| Model Name | M.2 (S80) 3TG6-P |
|---|---|
| Flash Type | 3D TLC |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | M.2 2280 B+M Key |
| Capacity | 128GB ~ 2TB |
| Sequential R / W (MB/sec, max.) | 560 / 520 |
| P/E Cycle | 3,000 |
| TBW (Max.) | 4,615 |
| Storage Temperature | -40°C ~ 85°C |
| Max. Power Consumption | 3.1W (3.3V x 939mA) |
| Max. Channels | 4 |
| External DRAM Buffer | Y |
| Feature | PLP (iCell), AES, TCG Opal 2.0, H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 22.0 x 80.0 x 3.8 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | 1500G@0.5ms |
| MTBF | >3 million hours |
| Warranty | 3 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
128GB | DGM28-A28M71*C%#F(S) | DGM28-A28M71*W%#F(S) |
256GB | DGM28-B56M71*C%QF(S) | DGM28-B56M71*W%QF(S) |
512GB | DGM28-C12M71*C%QF(S) | DGM28-C12M71*W%QF(S) |
1TB | DGM28-01TM71*C%QF(S) | DGM28-01TM71*W%QF(S) |
2TB | DGM28-02TM71*C%QF | DGM28-02TM71*W%QF |
*. E : 64 layers 3D TLC / G : 96 layers 3D TLC / K : 112 layers 3D TLC
%. 1 / A / B : PCB version control
#. D : 2 channels / Q : 4 channels
S. : Single side
