M.2
8GB ~ 64GB
M.2 (S42) 3IE3
Features
- SATA 6.0Gb/s interface
- iSMART disk health monitoring
- Intelligent error recovery system
- Excellent data transfer speed
- Zero mechanical interference
- Anti-vibration mechanical design
Innodisk M.2 (S42) 3IE3 is designed as the standard M.2 form factor with SATA interface, and supports SATA III standard (6.0Gb/s) with excellent performance. The form factor refers to the M.2 (NGFF) specification which established by JEDEC. Regarding of mechanical interference, Innodisk M.2 (S42) 3IE3 absolutely replaces the traditional hard disk and makes personal computer, in any field, smaller and easier.
Innodisk M.2 (S42) 3IE3 effectively reduces the booting time of operation system, and the power consumption is less than hard disk drive (HDD), and complies with ATA protocol, no additional drivers are required, and can be configured as a boot device or data storage device.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
INDUSTRIAL / EMBEDDED
Designed for harsh environments, our products offer high durability to meet the demands of industrial automation and embedded systems.
ENTERTAINMENT
Our products enhance user experiences in gaming systems and entertainment platforms, ensuring smooth operations and meeting industry standards.
AUTOMATION
Enhancing efficiency in automated systems, our products provide precise data management and long-lasting performance in industrial applications.
SPECIFICATIONS
| Model Name | M.2 (S42) 3IE3 |
|---|---|
| Flash Type | iSLC (MLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | M.2 2242 B+M Key |
| Capacity | 8GB ~ 64GB |
| Sequential R / W (MB/sec, max.) | 200 / 80 |
| P/E Cycle | 20,000 |
| TBW (Max.) | 694 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 1.3W |
| Max. Channels | 2 |
| External DRAM Buffer | N |
| Feature | S.M.A.R.T. |
| Dimension (W x L x H/mm) | 22.0 x 42.0 x 3.2 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | [email protected] |
| MTBF | >3 million hours |
| Warranty | 5 Years |
ORDER INFORMATION
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
8GB | DHM24-08GD09BC1SC | DHM24-08GD09BW1SC |
16GB | DHM24-16GD09BC1DC | DHM24-16GD09BW1DC |
32GB | DHM24-32GD09BC1DC | DHM24-32GD09BW1DC |
64GB | DHM24-64GD09BC1DC | DHM24-64GD09BW1DC |
